Dewatering screw press is an efficient solution for pretreating high-organic-content waste like food scraps and kitchen waste. Designed to streamline the process, it shortens pretreatment time, offers quick startup, and adapts easily to various materials.
Our dewatering screw press delivers efficient, continuous processing within a compact footprint, making it ideal for facilities with limited space. It is specifically engineered to handle challenging materials that are prone to clogging, ensuring consistent and reliable operation even under demanding conditions.
With user-friendly operation and low maintenance needs, our dewatering screw press is an ideal choice for efficient and cost-effective waste management.
| Dimensions (L×W×H) | 5580×1900×4000mm |
| Machine weight | Approx. 8T |
| Screw diameter | 650mm |
| Rotation speed | 8-25r/min |
| Screw pitch | Varying pitch |
| Pressure adjustment range | 0-5MPa |
| Screen hole diameter | Customizable (slot or hole) |
| Installation power | 37kW+4kW (hydraulic system) |
| Material of main components | Stainless steel, alloy steel, 45#steel/carbon steel |
| Max. effective torque | 12000N.m |
| Max. design torque | 13000N.m |
| Max. size of repair part | Ø650×4500 |
| Max. weight of repair part | Approx. 1800kg |
| Gear reducer | SEW, Siemens, Hansen, or other brands |
| Motor | Variable frequency motor (domestic reliable brand) |
| Bearing | FAG\SKF\NSK |
| Screening size | 0-2mm |
| Screw coating | Hardened with tungsten carbide coating for wear protection |
