The PEAKS-ECO mobile cone crusher combines the crusher, truck-mounted feeder, vibrating screen, and other components into a single integrated unit. With enhanced speed and stroke, it significantly increases rated power and processing capacity.
Designed as a compact, all-in-one system, it minimizes footprint while maximizing efficiency. Equipped with a generator, motor, and control cabinet, it is well-suited for outdoor operations.
Offering multiple power options, including external power supply and dual-fuel, the machine adapts seamlessly to varying operational needs. Its user-friendly touchscreen interface and wireless remote control provide convenient, safe operation.
| Model |
|
|
|
|
| Max. feeding size (mm) | 215 | 215 | 250 | 215 |
| Crusher model | AGP300 | AGP300 | AGP400 | CC440 |
| Crusher power (kW) | 250 | 250 | 315 | 250 |
| Discharge port adjustment range (mm) | 10-45 | 10-45 | 10-51 | 8-44 |
| Capacity (t/h) | 100-380 | 100-380 | 140-500 | 100-350 |
| Working power (kW) | 317 | 317 | 436 | 313 |
| Dimensions (L×W×H) (m) | 18.0×4.0×4.0 | 18.0×4.0×4.0 | 20.0×4.0×4.0 | 18.0×4.0×4.0 |
| Machine weight (t) | 50 | 56 | 76 | 50 |
